Square Compressed Air Motor for Pneumatic Hydraulic Pumps

Foot-Operated Air Over Hydraulic Pump for Pneumatic Systems, Single Unit
✔️ Foot-actuated pump, 70 MPa max hydraulic, 0.7-1.0 MPa air, 1/4 NPT

The air over hydraulic pump is designed for single-acting ram applications in industrial and construction settings, delivering precise and adjustable pressure with a user-friendly foot control.

✅ Working pressure: 0.7-1.0 MPa
✅ Max hydraulic pressure: 70 MPa
✅ Air pressure: 108-120 psi
✅ Air consumption: 11 SCFM (under 100 psi/6.9 bar)
✅ Input port: 1/4" NPT; Output port: M20X1.5
✅ External dimension: 95 x 95 x 175 mm (3.74 x 3.74 x 6.89 in)
✅ Cylinder inner diameter: 70 mm (2.76 in)
✅ Pump core outer diameter: 6 mm (0.24 in)
✅ Pack: 1 unit

💡 What is an air powered hydraulic pump used for in single acting ram applications?

In everyday use, this handy device delivers rapid, controlled hydraulic force driven by compressed air.

- Handy for lifting, pressing, and clamping tasks in industrial settings - Foot actuated control speeds setup and reduces operator fatigue - Compatible with 0.7-1.0 MPa air supply and up to 70 MPa hydraulic pressure
