UCP204CE 20mm Pillow Block Bearing, Wide Inner Ring, Set-Screw Lock, Cast Iron P204N Housing with Pressed Steel Cover, Sealed Ball Bearing, 1 per Pack, 1/4-28 UNF Grease Tap

20mm UCP204CE Pillow Block Bearing, Wide Inner Ring
✔️ Set-screw lock, sealed ball bearing, 1/4-28 UNF grease tap, 1 per Pack

This single UCP204CE pillow block bearing is a general purpose mounted unit for supporting rotating shafts in conveyors, fans, pumps, and light industrial gear. It includes a sealed ball bearing with relubrication capability.

✅ Model: UCP204CE, 20mm I.D., wide inner ring
✅ Housing: Cast iron P204N, standard duty housing
✅ Cover: Pressed steel protective cover
✅ Insert: Ball bearing, bearing steel material
✅ Locking: Set screw type, bolt size M10
✅ Lubrication: 1/4-28 UNF grease fitting tap, relubrication OK
✅ Seal: Contact seal with slinger for light contamination protection
✅ Temp rating: Up to 212F, HTS 8483.20.40.40

💡 What is a pillow block bearing used for? They provide mounted support for rotating shafts and make it easy to install sealed ball bearings. - Mount and support conveyor shafts, fan spindles, pump shafts, and gearbox inputs with reliable rotation - Quick install for sealed ball bearing units and simple relubrication using a 1/4-28 UNF grease tap - Handy for retrofits or linear slide unit conversions in light industrial and maintenance work
