UCP202-10NPMZ2 Pillow Block Bearing 5/8 in Bore Nickel-Plated P203NP Cast Iron Housing Zinc-Plated Wide Inner Ring Ball Insert Set-Screw Lock Sealed Contact Slinger, 3/8 in Bolt Size

5/8 in Pillow Block Bearing, Nickel Housing
✔️ Zinc ball insert, set-screw lock, sealed, relube port 1/4-28

This single pillow block bearing features a sealed ball insert in a nickel-plated P203NP cast iron housing, ideal for general purpose shafts, conveyors, and light industrial equipment.

✅ Model: UCP202-10NPMZ2 with UC202-10MZ2 insert
✅ Bore (I.D.): 5/8 in
✅ Inner ring: Wide, zinc-plated ball insert
✅ Housing: Nickel-plated cast iron P203NP
✅ Locking: Set-screw S-S lock
✅ Bolt size: 3/8 in for mounting
✅ Seal: Contact seal with slinger, sealed ball bearing
✅ Lubrication: 1/4-28 UNF fitting, relubricatable
✅ Max temp rating: 212°F

💡 What is a pillow block bearing used for? A pillow block supports a rotating shaft and keeps components aligned for smooth operation. - Supports shafts on fixed mounts for conveyors, pumps, and agricultural gear while reducing vibration and wear. - Sealed ball bearing pillow blocks offer protected, relubricatable performance for longer service life. - Handy for simple linear slide unit arrangements, light drives, and shop machinery that need easy installation and reliable shaft support.
