SME10GUU NB 10mm Open Block Unit Motion Linear Bearing
SME10GUU NB 10mm Open Block Unit Motion Linear Bearing
Regular price
$196.05 CAD
Regular price
$264.66 CAD
Sale price
$196.05 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
| SME10GUU NB Open Block Type:Slide Unit Made in Japan:NB Linear Systems Nippon Bearing Linear Systems |
SME10GUU NB Open Block Slide Unit, The inner contact diameter is 10mm, The retainer material is resin, Series mainly used in the USA, NB brand (Nippon Bearing Linear Systems), made in Japan.
|
| Major Dimensions | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Inner Contact Diameter (mm) | Outer Dimensions | Mounting Dimension | ||||||||
| h | E | W | L | F | T | h1 | B | C | S | |
| 10 | 15 | 18 | 36 | 32 | 24 | 7 | 6 | 25 | 20 | M5 |
