45TAC10DU P4 Bearing Nachi Ball Screw Support Japan 45x100x20 Bearing

45TAC10DU P4 Nachi Ball Screw Support Bearing, Bearing has the ability to achieve high precision and high performance on your applications, 45TAC10DB supports precision actuators in a wide range of applications such as machine tools, precision measuring equipment, and robot technologies, Made in Japan.

• 45TAC10DU P4 Support Bearing
• Nachi Ball Screw Support Bearing
• Quality: ABEC-7 (P4)
• Dimensions: 45mm x 100mm x 20mm/Metric
• ID (inner diameter)/Bore: 45mm
• OD (outer diameter): 100mm
• Width: 20mm
• Size: 45 x 100 x 20 mm
• Quantity: 1 Bearing
• Dynamic load rating Cr: 68,000 N
• Axial limiting Load: 113,000 N
• Limiting Speed:
  • Grease Lubrication: 2,850 RPM
• Made in Japan

• Energy Saving
• Easy Assembly
• Simple and Compact
• High Axial Rigidity
• High Capacity and Low Noise
